This product is an outdoor environmentally friendly mosquito control device based on a solar-powered system. It works in conjunction with a UV insect-attracting light source and an aerodynamic negative pressure fan system to continuously attract and physically capture flying insects.
Key Technical Features
Monocrystalline Solar Charging System: Employs high-efficiency monocrystalline silicon photovoltaic modules to provide a stable power input to the system. Actual power generation efficiency is affected by light intensity and installation angle.
Brushless DC Suction Motor: Utilizes an industrial-grade brushless motor to drive the airflow system, providing stable negative pressure suction with low noise, suitable for quiet nighttime environments.
Grade-A Lithium Battery System: Employs a new lithium battery energy storage solution with basic overcharge/over-discharge protection, supporting long-term cyclic charging and discharging use.
Chemical-Free Pest Control: The product does not rely on any chemical agents or gases, controlling insect populations through physical methods, making it more suitable for environmentally sensitive areas.
Weather-Resistant Housing: Features a UV-resistant engineering plastic shell design, suitable for long-term use in rainy, high-humidity, and high-temperature environments.
Anti-Escape Collection System: Employs a unidirectional airflow structure design internally to reduce the probability of insect escape and improve capture efficiency.
Smart Light Sensor Control: Automatically detects changes in ambient brightness, enabling unmanned operation by starting at night and shutting off during the day.
Low-Noise Airflow Design: Optimized airflow structure reduces airflow noise, making the device suitable for quiet residential and commercial areas.
Technical Specifications
|
Item |
Specification |
Notes |
|
Solar Panel |
Monocrystalline Silicon 5V / 5W |
Typical efficiency depends on sunlight conditions |
|
Battery |
3.7V Lithium Battery (2000–6000mAh optional) |
Rechargeable, Grade-A cells used |
|
UV Light Source |
365–395nm UV LED |
Wavelength optimized for insect attraction |
|
Motor Type |
Brushless DC Motor |
Low noise operation system |
|
Noise Level |
<45dB (1m distance, typical condition) |
May vary by installation environment |
|
Waterproof Rating |
IP65 |
Suitable for outdoor rain exposure |
|
Housing Material |
UV-resistant ABS + PC |
Outdoor durability design |
|
Effective Area |
50–150㎡ (typical outdoor condition) |
Depends on environment factors |
|
Charging Time |
6–8 hours (full sunlight condition) |
Weather dependent |
|
Working Time |
8–12 hours per full charge |
Based on battery configuration |
|
Certifications |
CE, RoHS, FCC, MSDS, UN38.3 |
Documents available upon request |
Applications
Outdoor Retail and Gardening Market
This product is suitable for home patios and gardening retail channels. As a seasonal, high-demand product, it possesses excellent point-of-sale and gift attributes.
Hotel and Commercial Outdoor Spaces
Suitable for hotel terraces, restaurant outdoor areas, and resort environments, it reduces noise and visual disturbance caused by traditional electric shock devices.
Agricultural and Public Environmental Management
Suitable for large outdoor spaces such as farms, orchards, and municipal parks, providing basic insect control functions without an electric grid.
Manufacturing & QC
Factory Production Capacity
The factory is equipped with multiple outdoor electronic product assembly lines, supporting stable mass production and seasonal order delivery, and possesses basic incoming material inspection and finished product testing capabilities.
Quality Control Process
Before leaving the factory, products undergo multiple basic tests, including functional testing, waterproof testing, light source testing, and battery charge/discharge testing, to ensure product stability under normal use conditions.
Packaging & Shipping
Standard Packaging Information
Single Item Packaging: Approx. 220 × 220 × 350 mm (including shockproof lining)
Outer Carton Dimensions: 10 pcs / carton (approx. 460 × 460 × 720 mm)
Gross Weight: Approx. 14–15 kg / carton (may vary slightly depending on configuration)
Shipping Support
Supports international trade terms such as EXW / FOB / CIF. DDP solutions can be provided according to customer needs (subject to the logistics policies of the destination country).
Customization Services
Brand Customization Capabilities: Supports logo silkscreen printing, laser marking, and packaging customization to meet the basic OEM needs of Amazon, retailers, and brand clients.
Product Structure Customization: Battery capacity, solar panel size, and exterior color can be adjusted to suit different climates and application environments based on varying market demands.
Function Expansion Capabilities: Supports basic function upgrades, such as adding sensing modules, landscape lighting modes, or mobile control solutions (subject to project requirements assessment).
Order Process
Product Consultation and Needs Confirmation
Quotation and Specification Confirmation
Sample Testing and Verification
Formal Order Placement and Deposit Payment
Mass Production and QC Inspection
Shipping and Logistics Arrangement
After-sales Support and Replacement Parts Service
