Description

Technical Parameters

The Wireless Soil Moisture Monitoring Station is an automated, field-deployed system designed to measure volumetric water content (VWC), soil temperature, and electrical conductivity (EC) across multiple depth profiles.

Product Parameters

Parameter	Value
VWC Accuracy	±2%
Probe Lengths	30cm / 60cm / 90cm (10cm segments)
Soil Temperature Range	-40°C to +80°C (±0.5°C)
Soil EC Range	0–10 dS/m (±5%)
Cellular Connectivity	LTE-M (Cat-M1) / NB-IoT, 2G fallback
LoRaWAN Range	Up to 15 km (LoS)
Battery	3.2V 10,000mAh LiFePO4
Solar Panel	5W monocrystalline
Battery Autonomy	60 days (15-min sampling / 60-min upload)
Low-Temp Operation	Down to -20°C

Key Features

FDR Technology & VWC Accuracy: 100 MHz FDR technology reduces salinity and texture interference, delivering ±2% VWC accuracy across standard soils.

Multi-Depth Gradient Mapping: 30cm/60cm/90cm probes with sensor nodes every 10cm, enabling continuous root-zone moisture mapping.

Dual-Telemetry Infrastructure: Multi-band LTE-M/NB-IoT with 2G fallback (AT&T, Verizon, Vodafone certified) or regional LoRaWAN (US915/EU868/AU915) with 15km LoS range.

Solar-Powered Energy System: 3.2V 10,000mAh LiFePO4 battery (>2,000 cycles) + 5W solar panel, sustaining 15-min sampling / 60-min upload for 60+ days without sunlight.

Industrial Applications

Agricultural Irrigation Management: Tracks real-time, multi-depth VWC gradients in almond, citrus, wine grape, corn, wheat, and soybean cultivation, enabling a verifiable 25% reduction in irrigation water volume and optimized fertilizer application scheduling.

Geotechnical Infrastructure Monitoring: Monitors structural sub-surfaces along railway embankments, highway cuts, and structural foundations, delivering automated risk alerts based on moisture saturation thresholds.

After-Sales Service

24-Month Warranty: All stations include a 24-month factory warranty. Replacement components are dispatched via air freight within 3–5 working days to minimize field downtime.

Engineering Access: Guaranteed 24-hour SLA response for API integration and firmware updates, connecting your technical team directly to our Tier-3 hardware and software engineers.

Certifications & Compliance

Regulatory Compliance (FCC & CE-RED): Certified under FCC Part 15 Class B and CE-RED directives, meeting international electromagnetic compatibility (EMC) and radio frequency (RF) standards.

NIST-Traceable Calibration: Factory-calibrated against NIST standards with pre-loaded coefficients for sand, loam, clay, and peat. Each unit includes a serialized NIST certificate accessible via the cloud platform.

Environmental Safety (RoHS): Verified compliance with EU RoHS Directive 2011/65/EU and amendment 2015/863, ensuring zero heavy metal contamination in agricultural and food-production zones.

IEC & ASTM Environmental Testing: Enclosures and sensors are tested to IEC 60068-2-6 vibration standards and ASTM B117 salt spray standards (500 hours), extending equipment lifecycles.

FAQ

Q: How long can unopened pheromone lures be stored?

A: Unopened lures remain effective for up to 24 months when stored at 0–8°C in their original sealed foil packaging.

Q: What storage conditions are recommended before field use?

A: Store the lures in a dry environment away from direct sunlight at 0–8°C. Avoid repeated freezing and thawing, as this may shorten the pheromone release period.

Q: What trap types are compatible with this lure?

A: The lure fits standard funnel traps, delta traps, and bucket traps with a 6mm septa opening; free compatibility guides are available on request.

Q: How many traps should be installed per hectare?

A: For routine monitoring, 2–4 traps per hectare are generally recommended. During heavy infestations or mass trapping programs, trap density can be increased to 10–20 traps per hectare, depending on local pest pressure.

Q: What happens if the lure underperforms in my region's climate?

A: We offer a performance guarantee: if verified trap-catch data falls below regional benchmarks within 30 days, we provide a free replacement batch or a formulation adjustment.

Q: Can you provide references from existing distributors or cooperatives?

A: Yes, we can share contact references from current distributors in Southeast Asia and East Africa upon request, subject to a standard NDA.

Q: Do you have third-party lab verification for your isomer purity claims?

A: Yes, each production batch is independently tested by SGS or an equivalent accredited lab, with certificates provided alongside our internal GC-MS reports.
